30L Max Layer Multilayer PCB Assembly with 1500*1200mm Max Size and +/-10% Impedance Control

30L Max Layer Multilayer PCB Assembly with 1500*1200mm Max Size and +/-10% Impedance Control

30L Max Layer Multilayer PCB Assembly

1500*1200mm Max PCB Assembly

+/-10% Impedance Control PCB Assembly

Luogo di origine:

Cina/Cambogia

Marca:

Suntek

Certificazione:

ISO9001, ISO13485, TS16949 and UL E476377

Numero di modello:

SE45

Contattaci
Chiedi un preventivo
Dettagli del prodotto
Materiale di base:
FR4, Rogers, senza alogene
Materiale di costruzione:
RCC,FR4
Livello massimo:
30L
Dimensione massima del PCB ((mm):
1500*1200 mm
Peso di rame di base:
1/4OZ-2OZ
Controllo dell'impedenza:
+/-10%
Finitura superficiale:
ENIG/OSP/HASL/Au Plating/Immersion Tin
Tolleranza della PTH:
+/- 0,05 mm
Termini di pagamento e di spedizione
Quantità di ordine minimo
5 pezzi
Prezzo
1-100USD/PCS
Imballaggi particolari
Violo, anti-static, ESD, cartoni
Tempi di consegna
1 settimana dopo tutti i componenti raccolti
Termini di pagamento
T/T,T/T,Paypal
Capacità di alimentazione
100 pezzi/ora
Descrizione del prodotto
Multilayer PCB Assembly Manufacturer New Energy Circuit Board With Impedance Control
Suntek Group is a leading supplier in EMS field with one-stop solution for PCB/FPC assembly, Cable assembly, Mix technology assembly and Box-buildings.
We have 2 manufacturers, one in China, other one in Cambodia.
30L Max Layer Multilayer PCB Assembly with 1500*1200mm Max Size and +/-10% Impedance Control 0 30L Max Layer Multilayer PCB Assembly with 1500*1200mm Max Size and +/-10% Impedance Control 1
PCB-PCBA Applications:
  • Automobiles, Machinery
  • Electronical machine, Projector
  • Advertising machine, Monitor, Home appliance
  • Water Dispensers, Computer, Motherboard
  • Military equipment, Air conditioner
  • Communications-equipment, Power device, etc.
30L Max Layer Multilayer PCB Assembly with 1500*1200mm Max Size and +/-10% Impedance Control 2
Frequently Asked Questions
Q1: What files do you use in PCB fabrication?
A1: Gerber, BOM, Drawings.
Q2: How do you make sure the quality?
A2: Our Product is all 100% E-tested. PCB Assembly are with 100% AOI, ICT, FT and Visual checking, 100% X-ray for BGA.
Q3: Can we visit your company?
A3: Of course, Welcome to visit our company, Suntek located in Xingsha Industrial Park, Changsha, Hunan province, China.
Q4: What is the lead time?
A4: It takes 3-5 working days for sample, 7-10 working days for batch production based on files and quantity. It takes 15-20 working days for PCB assembly.
Q5: Will you keep our information and files secret?
A5: Sure, It is our basic principle to keep business secrets to protect our customers' designs. NDA can be signed at any time.
Q6: How to work with you?
A6:
- Email and send us the PCB layout file, BOM list
- We will provide reply confirmation within 12 hours and reply to the offer within 3-5 days
- Waiting for your company to confirm the price, order and payment terms
- We will proceed the order
